16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King

Product Categories
Shenzhen UT-King Technology Co., Ltd.
Contact Now

16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King

  • 1
  • 2

Model Number : Huawei GPFD

Place of Origin : Guangdong, China

Brand Name : Huawei

Packaging Details : carton

Price : $2,100.00/pieces 1-9 pieces

Type : OLT

Use : FTTH FTTB FTTX Network

Warranty Time : 1Year

Network : Wireless Lan, Wired LAN, wifi

Product name : Huawei GPFD Service Board

Model : GPFD

Service Port : 16-GPON Port

Operating Wavelength : Tx: 1490 nm, Rx: 1310 nm

Encapsulation Type : SFP

Optical Connector Type : SC/UPC

Port Rate : Tx: 2.49 Gbit/s, Rx: 1.24 Gbit/s

Packing : Carton

Dimensions : 22.86 mm x 237.00 mm x 395.40 mm

Keywords : service board huawei gpon

Contact Now

16 port GPON OLT interface board with B+ C+ and C++ SFP module Huawei GPFD Service Card
Product Description
Huawei GPFD Service Board is a 16 port GPON interface card This board offers GPON service access from ONT which get maximum access 16*128 GPON subscribers. The OLT product is positioned as an optical access device OLT, which supports GPON, 10G GPON, EPON, 10G EPON, and P2P access modes, and provides services such as Internet access, voice, and video. As a large, medium and small series of products, several products have a total of software platforms and service boards.

SmartAX MA5680T/MA5683T/MA5608T equipment is a GPON/EPON integrated optical access product launched by Huawei Technologies Co.,Ltd. It has ultra-high aggregation switching capacity, 3.2T backplane capacity, 960G switching capacity, 512K MAC address capacity, and supports up to 44 channels of 10 GE or 768 GE access.The software versions of the three specifications are fully compatible with the user board, saving the types and quantity of spare parts and reducing maintenance costs.
Specification
Brand
Huawei
Model
GPFD
GPON Port
16-GPON Port
Type
C+ Module : One-fiber bi-directional optical module, class C+
Operating Wavelength
Tx: 1490 nm, Rx: 1310 nm
Encapsulation Type
SFP
Port Rate
Tx: 2.49 Gbit/s, Rx: 1.24 Gbit/s
Minimum Output Optical Power
C+ Module : 3.00 dBm
Maximum Output Optical Power
C+ Module : 7.00 dBm
Maximum Receiver Sensitivity
C+ Module : -32.00 dBm
Optical Connector Type
SC/PC
Optical Fiber Type
Single-mode
Reach
20.00 km
Overload Optical Power
C+ Module : -12.0 dBm
Extinction Ratio
8.2 dB
Dimensions (W x D x H)
22.86 mm x 237.00 mm x 395.40 mm
Power Consumption
H802GPFD : Static: 45 W, Maximum: 73 W
H803GPFD : Static: 39 W, Maximum: 61 W
H805GPFD : Static: 26 W, Maximum: 50 W
Maximum Frame Size
2004 bytes
Operating temperature
-25°C to +65°C
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
Details Images
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
Company Profile
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
16 Port GPON OLT Interface Board With B+ C+ And C++ SFP Module UT-King
FAQ
1. who are we?
We are based in Guangdong, China, start from 2015,sell to South America(30.00%),North America(15.00%),Southeast Asia(15.00%),Mid East(10.00%),Domestic Market(10.00%),Eastern Europe(5.00%),Eastern Asia(5.00%),Western Europe(5.00%),Central America(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
ONU,Fiber Optic Fast Connector,Fiber Optic PLC Splitter,Fiber Optic Distribution Box,Fiber Cable.

4. why should you buy from us not from other suppliers?
We specialize in manufacturing and selling of fiber optic products and accessories. Rich experiences in massive production of fiber optical products ensure the reliable stabilities of its high quality and excellent performances of its goods.

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,CIP,DDP；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Portuguese,Russian
